TYPE 6004
STRAIGHT CUP GRINDING WHEELS WITH THREADED INSERT
TYPE 6004 grinding wheels are mounted using a threaded insert. They work with the face surface. TYPE 6004 grinding wheels are mainly used on track mounted machines for grinding and reconditioning rails. They can also be used on hand held grinders if : D ≤ 180, T ≤ 70 and E ≥ 0.25T.
ANDRE TYPE 6004 resin bonded grinding wheels are manufactured mainly on the basis of brown aluminium oxide (95A) and zirconia aluminium oxide (ZRA). For special applications, ANDRE also offers other combinations of abrasive grains with excellent performance characteristics.
E ≥ 0,2T - for stationary grinders
E ≥ 0,25T - for handheld grinders
E ≥ 0,25T - for handheld grinders
6004 - D x T x H - W...E...
Examples of labeling:
6004 - 150x80xM20-W50E20-10ZRA16T7B736-63
6004 - 150x80xM20-W50E20-10ZRA16T7B736-63
Download
Parameters of the offered grinding wheels of the presented type
| TYPE 6004 | ||||
| Dimensions [mm] | ||||
| D | T | H | W | E |
| 152 | 80 | M20 | 50 | 20 |
*) Other parameters (dimensions, profiles) available according to individual arrangements.
The presented abrasive tools ANDRE ABRASIVE ARTICLES have been manufactured based on knowledge and long-term experience of cooperation with customers.
Since the beginning of its activity, ANDRE company has been focusing on high quality of its products. At ANDRE, every effort is made to ensure that products meet customers' individual needs and satisfy their highest expectations even in the most difficult grinding operations.
Abrasive tools by ANDRE ABRASIVE ARTICLES are safe.
ANDRE gradually improves its technological process to offer abrasive tools with increasingly better usability and a high safety factor in accordance with the applicable standards. Membership in organizations of leading abrasive tool manufacturers and regular certification fully confirm that.
