TYPE VDA-14

DIAMOND AND BORON GRINDING WHEELS

Superhard TYPE VDA-14 resin-bonded grinding wheels are used, for sharpening the tooth clearance surfaces of circular saws with carbide inserts. These are double-layer grinding wheels and can be used on CNC and conventional stationary grinding machines.

ANDRE TYPE VDA-14 super-hard resin bonded grinding wheels are produced on the basis of diamond or borazon grains, depending on the nature of the operation and the type of material to be machined.
For specialized applications, ANDRE also offers customized solutions of super-hard abrasive tools with excellent wear characteristics.

VDA-14 – D x T x W₁/W₂ x X x H

Examples of labeling:
VDA-14-125x18x3/2x6x32-D126/46C100/75MBL2

Download

DIMENSION TABLE
PRODUCT EXAMPLES

Parameters of the offered superhard wheels of the presented type

TYPE VDA-14
Dimensions [mm]
D	T	W1	W2	X
125	18	3	2	6
125	22	3	2	10

*) Hole diameter H available according to individual arrangements.
**) Other parameters available according to individual arrangements.

Examples of manufactured superhard wheels of the presented type

D
Code	Dimensions [mm]	Characteristics
750734	125 × 18 × 3/2 × 6 × 32	D126/46C125/100O/PBL2
750447	125 × 18 × 3/2 × 6 × 32	D126/46C100/75LBL2

The presented abrasive tools ANDRE ABRASIVE ARTICLES have been manufactured based on knowledge and long-term experience of cooperation with customers.

Since the beginning of its activity, ANDRE company has been focusing on high quality of its products. At ANDRE, every effort is made to ensure that products meet customers' individual needs and satisfy their highest expectations even in the most difficult grinding operations.

Abrasive tools by ANDRE ABRASIVE ARTICLES are safe.

ANDRE gradually improves its technological process to offer abrasive tools with increasingly better usability and a high safety factor in accordance with the applicable standards. Membership in organizations of leading abrasive tool manufacturers and regular certification fully confirm that.
